Image shown is representative only. Exact specifications should be obtained from the product datasheet.
ARCOL 810F750E
Manufacturer
Manufacturer Product Number
810F750E
Description
10W 750 OHMS METAL-MITE 1%
Manufacturer Standard Lead Time Contact us
Detailed Description
750 Ohms ±1% 10W Wirewound Chassis Mount Resistor
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
ARCOL
Operating Temperature
-55°C ~ 275°C
Tolerance
±1%
Lead Style
Solder Lugs
Size / Dimension
0.750" L x 0.812" W (19.05mm x 20.63mm)
Features
-
Coating, Housing Type
Aluminum
Height - Seated (Max)
0.400" (10.16mm)
Failure Rate
-
Package / Case
Axial, Box
Mounting Feature
Flanges
Temperature Coefficient
±20ppm/°C
Composition
Wirewound
Power (Watts)
10W
Resistance
750 Ohms
Documents & Media
Resource Type
Link
Datasheets
EDA Models
Product Change Notices
Additional Resources
Attribute
Description
Part Number Alias
810F750E
822527
Availability
Out of Stock
Updated
5/16/2026
In-Stock: 0
Packaging Quantity Unit Price Ext Price
1 0Â â‚« 0Â â‚«
0Â â‚«
All prices are shown in the selected currency
