Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology DSPIC30F4012-20E/ML
Manufacturer
Manufacturer Product Number
DSPIC30F4012-20E/ML
Description
IC MCU 16BIT 48KB FLASH 44QFN
Manufacturer Standard Lead Time Contact us
Detailed Description
dsPIC dsPIC™ 30F Microcontroller IC 16-Bit 20 MIPS 48KB (16K x 24) FLASH 44-QFN (8x8)
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Number of I/O
20
Operating Temperature
-40°C ~ 125°C (TA)
DigiKey Programmable
Verified
Oscillator Type
Internal
Program Memory Type
FLASH
EEPROM Size
1K x 8
Core Processor
dsPIC
Data Converters
A/D 6x10b
Core Size
16-Bit
Mounting Type
Surface Mount
Supplier Device Package
44-QFN (8x8)
Speed
20 MIPS
Program Memory Size
48KB (16K x 24)
RAM Size
2K x 8
Package / Case
44-VQFN Exposed Pad
Voltage - Supply (Vcc/Vdd)
2.5V ~ 5.5V
Connectivity
CANbus, I2C, SPI, UART/USART
Peripherals
Brown-out Detect/Reset, Motor Control PWM, QEI, POR, PWM, WDT
Documents & Media
Resource Type
Link
Reference Designs
Design Resources
Training Modules
Environmental Information
Product Change Notices
Featured Products
Additional Resources
Attribute
Description
Part Number Alias
DSPIC30F4012-20E/ML
739420
DSPIC30F401220EML-ND
Availability
Out of Stock
Updated
5/16/2026
In-Stock: 0
Packaging Quantity Unit Price Ext Price
1 257.000 ₫ 257.000 ₫
257.000 ₫
All prices are shown in the selected currency
Tube · Digikey
Quantity Unit Price Ext Price
90
257.000 ₫
23.130.000 ₫
MOQ 90 · Order multiple 90
