Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology MCP23009-E/P
Manufacturer
Manufacturer Product Number
MCP23009-E/P
Description
IC XPNDR 3.4MHZ I2C 18DIP
Manufacturer Standard Lead Time Contact us
Detailed Description
IC XPNDR 3.4MHZ I2C 18DIP
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Operating Temperature
-40°C ~ 125°C
Interrupt Output
Yes
DigiKey Programmable
Not Verified
Voltage - Supply
1.8V ~ 5.5V
Output Type
Open Drain
Features
POR
Mounting Type
Through Hole
Clock Frequency
3.4 MHz
Supplier Device Package
18-PDIP
Interface
I2C
Number of I/O
8
Package / Case
18-DIP (0.300", 7.62mm)
Current - Output Source/Sink
25mA
Documents & Media
Resource Type
Link
Datasheets
Environmental Information
Additional Resources
Attribute
Description
Part Number Alias
MCP23009-E/P
2021350
MCP23009-E/P-ND
Availability
In Stock
Updated
5/16/2026
In-Stock: 68
Packaging Quantity Unit Price Ext Price
1 42.000 ₫ 42.000 ₫
42.000 ₫
All prices are shown in the selected currency
Tube · Digikey
Quantity Unit Price Ext Price
1
42.000 ₫
42.000 ₫
25
35.000 ₫
875.000 ₫
100
32.000 ₫
3.200.000 ₫
MOQ 1 · Order multiple 1
