Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology MCP23009-E/SS
Manufacturer
Manufacturer Product Number
MCP23009-E/SS
Description
IC XPNDR 3.4MHZ I2C 20SSOP
Manufacturer Standard Lead Time Contact us
Detailed Description
IC XPNDR 3.4MHZ I2C 20SSOP
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Operating Temperature
-40°C ~ 125°C
Interrupt Output
Yes
DigiKey Programmable
Not Verified
Voltage - Supply
1.8V ~ 5.5V
Output Type
Open Drain
Features
POR
Mounting Type
Surface Mount
Clock Frequency
3.4 MHz
Supplier Device Package
20-SSOP
Interface
I2C
Number of I/O
8
Package / Case
20-SSOP (0.209", 5.30mm Width)
Current - Output Source/Sink
25mA
Documents & Media
Resource Type
Link
Datasheets
Environmental Information
Additional Resources
Attribute
Description
Part Number Alias
MCP23009-E/SS
2021352
MCP23009-E/SS-ND
Availability
In Stock
Updated
5/16/2026
In-Stock: 1,540
Packaging Quantity Unit Price Ext Price
1 40.000 ₫ 40.000 ₫
40.000 ₫
All prices are shown in the selected currency
Tube · Digikey
Quantity Unit Price Ext Price
1
40.000 ₫
40.000 ₫
25
33.000 ₫
825.000 ₫
100
30.000 ₫
3.000.000 ₫
MOQ 1 · Order multiple 1
