Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology PIC16F1829LINT-E/SS
Manufacturer
Manufacturer Product Number
PIC16F1829LINT-E/SS
Description
IC MCU 8BIT 14KB FLASH 20SSOP
Manufacturer Standard Lead Time Contact us
Detailed Description
PIC PIC® XLP™ mTouch™ 16F Microcontroller IC 8-Bit 32MHz 14KB (8K x 14) FLASH 20-SSOP
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Product Status
Obsolete
Number of I/O
12
Operating Temperature
-40°C ~ 125°C (TA)
DigiKey Programmable
Verified
Oscillator Type
Internal
Program Memory Type
FLASH
EEPROM Size
256 x 8
Core Processor
PIC
Data Converters
A/D 9x10b
Core Size
8-Bit
Mounting Type
Surface Mount
Supplier Device Package
20-SSOP
Speed
32MHz
Program Memory Size
14KB (8K x 14)
RAM Size
1K x 8
Package / Case
20-SSOP (0.209", 5.30mm Width)
Voltage - Supply (Vcc/Vdd)
2.3V ~ 5.5V
Connectivity
I2C, LINbus, SPI, UART/USART
Peripherals
Brown-out Detect/Reset, POR, PWM, WDT, IBT LIN/J2602
Documents & Media
Resource Type
Link
EDA Models
Design Resources
Training Modules
Environmental Information
Product Change Notices
Featured Products
Errata
Environmental & Export Classifications
Attribute
Description
Product Status
Obsolete
Additional Resources
Attribute
Description
Part Number Alias
PIC16F1829LINT-E/SS
9923742
PIC16F1829LINT-E/SSCT-ND
PIC16F1829LINT-E/SSDKR-ND
PIC16F1829LINT-E/SSTR-ND
Availability
Out of Stock
Updated
5/16/2026
In-Stock: 0
Packaging Quantity Unit Price Ext Price
1 91.000 ₫ 91.000 ₫
91.000 ₫
All prices are shown in the selected currency
Cut Tape (CT) · Digikey
Quantity Unit Price Ext Price
1
91.000 ₫
91.000 ₫
MOQ 1 · Order multiple 1
Digi-Reel® · Digikey
Quantity Unit Price Ext Price
1
91.000 ₫
91.000 ₫
25
83.000 ₫
2.075.000 ₫
100
75.000 ₫
7.500.000 ₫
MOQ 1 · Order multiple 1
Tape & Reel (TR) · Digikey
Quantity Unit Price Ext Price
1,600
75.000 ₫
120.000.000 ₫
MOQ 1,600 · Order multiple 1,600
Alternate Packaging
PIC16F1829LIN-E/SS
IC MCU 8BIT 14KB FLASH 20SSOP
For Use With
MIKROE-798
EASYPIC V7 PIC18F45K22 EVAL BRD
4.649.000 ₫ MikroElektronika
MIKROE-2005
MIKROLAB FOR PIC MICRO MCU
14.674.000 ₫ MikroElektronika
DM164137
CURIOSITY 8/14/20 PIN PIC EVAL
1.392.000 ₫ Microchip Technology
MIKROE-2007
MIKROLAB FOR PIC XL MICRO MCU
19.945.000 ₫ MikroElektronika
Substitutes
PIC16F1829LINT-I/SS
IC MCU 8BIT 14KB FLASH 20SSOP
69.000 ₫ Microchip Technology
