Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology PIC16F685-E/SS
Manufacturer
Manufacturer Product Number
PIC16F685-E/SS
Description
IC MCU 8BIT 7KB FLASH 20SSOP
Manufacturer Standard Lead Time Contact us
Detailed Description
PIC PIC® 16F Microcontroller IC 8-Bit 20MHz 7KB (4K x 14) FLASH 20-SSOP
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Number of I/O
18
Operating Temperature
-40°C ~ 125°C (TA)
DigiKey Programmable
Verified
Oscillator Type
Internal
Program Memory Type
FLASH
EEPROM Size
256 x 8
Core Processor
PIC
Data Converters
A/D 12x10b
Core Size
8-Bit
Mounting Type
Surface Mount
Supplier Device Package
20-SSOP
Speed
20MHz
Program Memory Size
7KB (4K x 14)
RAM Size
256 x 8
Package / Case
20-SSOP (0.209", 5.30mm Width)
Voltage - Supply (Vcc/Vdd)
2V ~ 5.5V
Connectivity
-
Peripherals
Brown-out Detect/Reset, POR, PWM, WDT
