Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology PIC16F687T-E/SS
Manufacturer
Manufacturer Product Number
PIC16F687T-E/SS
Description
IC MCU 8BIT 3.5KB FLASH 20SSOP
Manufacturer Standard Lead Time Contact us
Detailed Description
PIC PIC® 16F Microcontroller IC 8-Bit 20MHz 3.5KB (2K x 14) FLASH 20-SSOP
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Number of I/O
18
Operating Temperature
-40°C ~ 125°C (TA)
DigiKey Programmable
Verified
Oscillator Type
Internal
Program Memory Type
FLASH
EEPROM Size
256 x 8
Core Processor
PIC
Data Converters
A/D 12x10b
Core Size
8-Bit
Mounting Type
Surface Mount
Supplier Device Package
20-SSOP
Speed
20MHz
Program Memory Size
3.5KB (2K x 14)
RAM Size
128 x 8
Package / Case
20-SSOP (0.209", 5.30mm Width)
Voltage - Supply (Vcc/Vdd)
2V ~ 5.5V
Connectivity
I2C, SPI, UART/USART
Peripherals
Brown-out Detect/Reset, POR, WDT
Documents & Media
Resource Type
Link
Datasheets
EDA Models
Design Resources
Related Documents
Training Modules
Environmental Information
Product Change Notices
Featured Products
Errata
Additional Resources
Attribute
Description
Part Number Alias
PIC16F687T-E/SS
964168
PIC16F687T-E/SS-ND
Availability
Out of Stock
Updated
5/16/2026
In-Stock: 0
Packaging Quantity Unit Price Ext Price
1 78.000 ₫ 78.000 ₫
78.000 ₫
All prices are shown in the selected currency
Tape & Reel (TR) · Digikey
Quantity Unit Price Ext Price
1,600
78.000 ₫
124.800.000 ₫
MOQ 1,600 · Order multiple 1,600
Alternate Packaging
PIC16F687-E/SS
IC MCU 8BIT 3.5KB FLASH 20SSOP
71.000 ₫ Microchip Technology
For Use With
MIKROE-798
EASYPIC V7 PIC18F45K22 EVAL BRD
4.649.000 ₫ MikroElektronika
MIKROE-2005
MIKROLAB FOR PIC MICRO MCU
14.674.000 ₫ MikroElektronika
MIKROE-2007
MIKROLAB FOR PIC XL MICRO MCU
19.945.000 ₫ MikroElektronika
Substitutes
PIC16F687-E/SS
IC MCU 8BIT 3.5KB FLASH 20SSOP
71.000 ₫ Microchip Technology
