Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology PIC16F819T-E/SO
Manufacturer
Manufacturer Product Number
PIC16F819T-E/SO
Description
IC MCU 8BIT 3.5KB FLASH 18SOIC
Manufacturer Standard Lead Time Contact us
Detailed Description
PIC PIC® 16F Microcontroller IC 8-Bit 20MHz 3.5KB (2K x 14) FLASH 18-SOIC
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Number of I/O
16
Operating Temperature
-40°C ~ 125°C (TA)
DigiKey Programmable
Verified
Oscillator Type
Internal
Program Memory Type
FLASH
EEPROM Size
256 x 8
Core Processor
PIC
Data Converters
A/D 5x10b
Core Size
8-Bit
Mounting Type
Surface Mount
Supplier Device Package
18-SOIC
Speed
20MHz
Program Memory Size
3.5KB (2K x 14)
RAM Size
256 x 8
Package / Case
18-SOIC (0.295", 7.50mm Width)
Voltage - Supply (Vcc/Vdd)
4V ~ 5.5V
Connectivity
I2C, SPI
Peripherals
Brown-out Detect/Reset, POR, PWM, WDT
Documents & Media
Resource Type
Link
Datasheets
EDA Models
Design Resources
Manuals
Related Documents
Training Modules
Environmental Information
Product Change Notices
Featured Products
Errata
Additional Resources
Attribute
Description
Part Number Alias
PIC16F819T-E/SO
9924056
PIC16F819T-E/SOCT-ND
PIC16F819T-E/SODKR-ND
PIC16F819T-E/SOTR-ND
Availability
In Stock
Updated
5/16/2026
In-Stock: 830
Packaging Quantity Unit Price Ext Price
1 118.000 ₫ 118.000 ₫
118.000 ₫
All prices are shown in the selected currency
Cut Tape (CT) · Digikey
Quantity Unit Price Ext Price
1
118.000 ₫
118.000 ₫
MOQ 1 · Order multiple 1
Digi-Reel® · Digikey
Quantity Unit Price Ext Price
1
118.000 ₫
118.000 ₫
MOQ 1 · Order multiple 1
Tape & Reel (TR) · Digikey
Quantity Unit Price Ext Price
1,100
97.000 ₫
106.700.000 ₫
MOQ 1,100 · Order multiple 1,100
Alternate Packaging
PIC16F819-E/SO
IC MCU 8BIT 3.5KB FLASH 18SOIC
97.000 ₫ Microchip Technology
For Use With
MIKROE-798
EASYPIC V7 PIC18F45K22 EVAL BRD
4.649.000 ₫ MikroElektronika
MIKROE-2005
MIKROLAB FOR PIC MICRO MCU
14.674.000 ₫ MikroElektronika
MIKROE-2007
MIKROLAB FOR PIC XL MICRO MCU
19.945.000 ₫ MikroElektronika
Substitutes
PIC16F819-E/SO
IC MCU 8BIT 3.5KB FLASH 18SOIC
97.000 ₫ Microchip Technology
