Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Microchip Technology PIC16LF1507T-I/SS
Manufacturer
Manufacturer Product Number
PIC16LF1507T-I/SS
Description
IC MCU 8BIT 3.5KB FLASH 20SSOP
Manufacturer Standard Lead Time Contact us
Detailed Description
PIC PIC® 16F Microcontroller IC 8-Bit 20MHz 3.5KB (2K x 14) FLASH 20-SSOP
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Microchip Technology
Number of I/O
17
Operating Temperature
-40°C ~ 85°C (TA)
DigiKey Programmable
Not Verified
Oscillator Type
Internal
Program Memory Type
FLASH
EEPROM Size
-
Core Processor
PIC
Data Converters
A/D 12x10b
Core Size
8-Bit
Mounting Type
Surface Mount
Supplier Device Package
20-SSOP
Speed
20MHz
Program Memory Size
3.5KB (2K x 14)
RAM Size
128 x 8
Package / Case
20-SSOP (0.209", 5.30mm Width)
Voltage - Supply (Vcc/Vdd)
1.8V ~ 3.6V
Connectivity
-
Peripherals
Brown-out Detect/Reset, POR, PWM, WDT
Documents & Media
Resource Type
Link
Datasheets
EDA Models
Design Resources
Environmental Information
Additional Resources
Attribute
Description
Part Number Alias
PIC16LF1507T-I/SS
9923758
PIC16LF1507T-I/SSCT-ND
PIC16LF1507T-I/SSDKR-ND
PIC16LF1507T-I/SSTR-ND
Availability
In Stock
Updated
5/16/2026
In-Stock: 2,735
Packaging Quantity Unit Price Ext Price
1 34.000 ₫ 34.000 ₫
34.000 ₫
All prices are shown in the selected currency
Cut Tape (CT) · Digikey
Quantity Unit Price Ext Price
1
34.000 ₫
34.000 ₫
25
33.000 ₫
825.000 ₫
MOQ 1 · Order multiple 1
Digi-Reel® · Digikey
Quantity Unit Price Ext Price
1
34.000 ₫
34.000 ₫
25
33.000 ₫
825.000 ₫
MOQ 1 · Order multiple 1
Tape & Reel (TR) · Digikey
Quantity Unit Price Ext Price
1,600
28.000 ₫
44.800.000 ₫
MOQ 1,600 · Order multiple 1,600
Alternate Packaging
PIC16LF1507-I/SS
IC MCU 8BIT 3.5KB FLASH 20SSOP
32.000 ₫ Microchip Technology
For Use With
MIKROE-798
EASYPIC V7 PIC18F45K22 EVAL BRD
4.649.000 ₫ MikroElektronika
MIKROE-2005
MIKROLAB FOR PIC MICRO MCU
14.674.000 ₫ MikroElektronika
MIKROE-2007
MIKROLAB FOR PIC XL MICRO MCU
19.945.000 ₫ MikroElektronika
