Molex 5055670231
Manufacturer
Manufacturer Product Number
5055670231
Description
1.25WB SGL RA ASSY 2CKT EMBPKG B
Manufacturer Standard Lead Time Contact us
Detailed Description
1.25WB SGL RA ASSY 2CKT EMBPKG B
Datasheet View datasheet
EDA/CAD Models
Product Attributes
Type
Description
Manufacturer
Molex
Operating Temperature
-40°C ~ 105°C
Connector Type
Header
Applications
Automotive, General Purpose, Industrial
Features
Pick and Place, Solder Retention
Contact Type
Male Pin
Fastening Type
Locking Ramp
Number of Positions Loaded
All
Termination
Solder
Voltage Rating
50VAC/DC
Current Rating (Amps)
Varies by Wire Gauge
Mounting Type
Surface Mount, Right Angle
Ingress Protection
-
Mated Stacking Heights
-
Number of Positions
2
Number of Rows
1
Material Flammability Rating
UL94 V-0
Style
Board to Cable/Wire
Insulation Color
Black
Pitch - Mating
0.049" (1.25mm)
Contact Finish - Mating
Gold
Contact Finish Thickness - Mating
15.0µin (0.38µm)
Contact Finish - Post
Gold
Contact Finish Thickness - Post
15.0µin (0.38µm)
Contact Material
Brass
Contact Shape
Square
Contact Length - Post
-
Insulation Height
0.154" (3.90mm)
Shrouding
Shrouded - 4 Wall
Overall Contact Length
-
Insulation Material
Polyamide (PA), Nylon, Glass Filled
Row Spacing - Mating
-
Contact Length - Mating
-
Documents & Media
Resource Type
Link
Datasheets
CAD Models
EDA Models
Related Documents
Product Change Notices
Additional Resources
Attribute
Description
Part Number Alias
5055670231
25862696
900-5055670231CT-ND
900-5055670231DKR-ND
900-5055670231TR-ND
Availability
In Stock
Updated
5/16/2026
In-Stock: 382
Packaging Quantity Unit Price Ext Price
1 34.000 ₫ 34.000 ₫
34.000 ₫
All prices are shown in the selected currency
Cut Tape (CT) · Digikey
Quantity Unit Price Ext Price
1
34.000 ₫
34.000 ₫
10
29.000 ₫
290.000 ₫
100
25.000 ₫
2.500.000 ₫
500
22.000 ₫
11.000.000 ₫
MOQ 1 · Order multiple 1
Digi-Reel® · Digikey
Quantity Unit Price Ext Price
1
34.000 ₫
34.000 ₫
10
29.000 ₫
290.000 ₫
100
25.000 ₫
2.500.000 ₫
500
22.000 ₫
11.000.000 ₫
MOQ 1 · Order multiple 1
Tape & Reel (TR) · Digikey
Quantity Unit Price Ext Price
1,200
23.000 ₫
27.600.000 ₫
2,400
22.000 ₫
52.800.000 ₫
3,600
21.000 ₫
75.600.000 ₫
6,000
21.000 ₫
126.000.000 ₫
8,400
20.000 ₫
168.000.000 ₫
12,000
20.000 ₫
240.000.000 ₫
MOQ 1,200 · Order multiple 1,200
