Image shown is representative only. Exact specifications should be obtained from the product datasheet.
Systium Technologies LLC 10708-254
Manufacturer
Manufacturer Product Number
10708-254
Description
80x25.4mm, 4 wire, PWM
Manufacturer Standard Lead Time 3 Days
Detailed Description
Fan 12VDC Square - 80mm L x 80mm H Ball 63.6 CFM (1.78m³/min) 4 Wire Leads
Datasheet View datasheet
Product Attributes
Type
Description
Manufacturer
Systium Technologies LLC
Operating Temperature
-10°C ~ 70°C
Size / Dimension
Square - 80mm L x 80mm H
Features
Auto Restart, PWM Control
Voltage Range
10.8 ~ 13.2VDC
Bearing Type
Ball
Termination
4 Wire Leads
Current Rating (Amps)
0.460A
Approval Agency
CE, TUV, UL
Lifetime @ Temp.
70000 Hrs @ 40°C
Noise
49.5dB(A)
Static Pressure
0.370 in H2O (92.2 Pa)
RPM
5000 RPM
Voltage - Rated
12VDC
Material - Frame
Plastic
Material - Blade
Plastic
Air Flow
63.6 CFM (1.78m³/min)
Width
25.40mm
Weight
0.156 lb (70.76 g)
Documents & Media
Resource Type
Link
Datasheets
Additional Resources
Attribute
Description
Part Number Alias
10708-254
25585244
5829-10708-254-ND
Availability
In Stock
Updated
5/16/2026
In-Stock: 1,549
Packaging Quantity Unit Price Ext Price
1 390.000 ₫ 390.000 ₫
390.000 ₫
All prices are shown in the selected currency
Bulk · Digikey
Quantity Unit Price Ext Price
1
390.000 ₫
390.000 ₫
MOQ 1 · Order multiple 1
